Mastercool – MC94103 – Compact 2-Way Manifold – Black Series Mini-fold

Mastercool - MC94103 - Compact 2-Way Manifold - Black Series Mini-fold

The Mastercool MC94103 Compact 2-Way Manifold from the Black Series provides a portable and powerful tool for technicians. Featuring a compact black anodized aluminum block with matte chrome fittings, this manifold allows for easy pressure and temperature calculations on a large blue backlit LCD display. The manifold is designed for precise refrigerant management, with automatic shut-off, unit conversion, over-range alarms, and refrigerant selection for up to 91 different refrigerants, including R134a, R410A, and R22. The unit's compact design and front-mounted hose holders offer increased portability and functionality, making it a valuable tool for busy technicians.

Key Features & Benefits:

• Compact and Durable Design: Black anodized aluminum block with matte chrome fittings for portability and durability.

• Easy Refrigerant Calculations: Performs pressure and temperature calculations for up to 91 refrigerants, including R134a, R410A, and R22.

• Unit Conversion: Allows conversion between MPa, kPa, bar, psi, kg/cm², and inHg for accurate readings across systems.

• Large LCD Display: 4-digit “blue” backlit LCD provides vibrant readings in dark environments for easy use.

• Alarm and Alerts: Includes over-range alarms, low battery warning, and Celsius/Fahrenheit options displayed directly on the LCD screen.

• Quick Visual Checks: Large sight glass for rapid refrigerant level checks.

• Easy-to-Grip Knobs: Provides better handling for technicians during use.

• Refrigerant Compatibility: Supports a wide range of refrigerants, from R11 to R744, making it suitable for various A/C and refrigeration systems.

Included Refrigerants:
R11, R113, R114, R115, R116, R12, R123, R1234yf, R1234ze, R124, R125, R13, R134a, R14, R141B, R142B, R413A, R152A, R161, R170, R21, R218, R22, R23, R290, R32, R401A, R401B, R401C, R402A, R402B, R403A, R403B, R404A, R406A, R407A, R407B, R407C, R407D, R407E, R407F, R408A, R409A, R409B, R41, R410A, R410B, R412A, R413A, R414A, R414B, R415B, R416A, R417A, R419A, R420A, R421A, R421B, R422A, R422B, R422C, R422D, R423A, R427A, R437A, R441A, R442A, R443A, R444A, R448A, R449A, R449B, R450A, R452A, R455A, R50, R500, R502, R503, R504, R507A, R508A, R508B, R509A, R513A, R600, R600a, R601, R601a, R740, R744.

Specifications:

• Pressure Range:

  • Low Pressure Range: -14.5 to 500 psi (-0.1 to 3.4 MPa)

  • High Pressure Range: -14.5 to 800 psi (-0.1 to 5.5 MPa)

• Resolution: 0.5 psi

• Accuracy: ±0.5% FS

• Measurement Units: MPa, kPa, bar, psi, kg/cm², inHg

• Temperature Unit: °C/°F

• Over Range Alarm: Display -OL-

• Operating Temperature: -10°C to 60°C

• Battery: CR2450

• Battery Life: Approximately 6 months

• Sampling Rate: 1 second

• Low Battery Indication: Icon on LCD

• Display: 30mm x 17mm LCD

• Blue Backlight: Auto-off after 6 seconds

• Connections: 1/4” SAE flare fittings

• Hose Holder: Front-facing hose holder for easy access

• Packaged: Zippered carry case for portability

Included Accessories:

• Hoses: No hoses included (sold separately)

• Carrying Case: Zippered carry case for storage and transport

Available Options:

• MC94103 Model – Compact 2-Way Manifold Gauge
